1. STANDRAT LOW PROFILE BOTTLE JACK SPECIFICATION (Dongkrak Bottol)
Rigidly adhering to JIS standards, Masada jacks boast excellent quality, modern design, and extremely high precision. These qualities have earned them a worldwide reputation for reliability.
Of welded construction throughout, Masada hydraulic jacks are light and durable. Masada’s unique base forging method increases resistance to high pressure and gives a degree of durability and performance not found in any other comparable products. As a result, many automobile manufactures choose Masada hydraulic jacks for their products. Among Masada’s clients are Isuzu, Mitsubishi, Fuso, Hino, Nissan Diesel, and Mazda.
Widely used in various fields such as machinery, construction, and Automotive industry.
All models work both in vertical and horizontal positions. All models have common release stem and valve assemblies, many other parts are also interchangeable from model to model.
Where applicable Masada jacks are certified to Australian Standards AS/NZS 2693-1993.
Full ranges of capacities are available from 2,000Kg to 100,000Kg see chart for sizes and specifications.
| Specification / Model | Capacity (ton) | Min. Height (mm) | Lift (mm) | Extension Screw Height (mm) | Max. Height (mm) | Weight (kg) | Price List (Rupiah) |
| MS - 2 | 2 | 180 | 115 | 50 | 345 | 2. 2 | 855.000 |
| MS - 3 | 3 | 190 | 115 | 60 | 365 | 2. 4 | 762.000 |
| MS - 5 | 5 | 200 | 120 | 70 | 390 | 4. 6 | 862.000 |
| MH - 10 | 10 | 240 | 150 | 80 | 470 | 7. 9 | 1.414.000 |
| MH - 15 | 15 | 265 | 165 | 80 | 510 | 10. 4 | 1.910.000 |
| MH - 20 | 20 | 270 | 160 | - | 430 | 12. 2 | 2.186.000 |
| MH - 30 Y | 30 | 280 | 160 | - | 440 | 18. 5 | 4.339.000 |
| MH - 50Y | 50 | 305 | 170 | - | 475 | 37. 0 | 11.868.000 |
| MH - 100Y | 100 | 305 | 145 | - | 450 | 93. 0 | 53.323.000 |
2. SERVICE JACK SPECIFICATIONS
1. Quality is the criteria with this equipment, a foot pedal-pumping device to raise the saddle to the load quickly.
2. Rear wheel castors are fitted to balance the weight of the jack enabling the operator to move the jack in any direction using the lockable handle and footplate on the rear of the jack.
3. Built-in automatic safety valves prevent overloading.
4. Overall construction of selected steels gives long and trouble free use.
SERVICE JACK SPECIFICATIONS (Dongkrak Buaya)
| Specification / Model | Capacity (ton) | Min. Height (mm) | Lift (mm) | Extension Screw Height (mm) | Max. Height (mm) | Weight (kg) | Price List (Rupiah) |
| SJ - 20S | 2 | 113 | 360 | 473 | 150 | 33 | 5.055.000 |
| SJ - 20L | 2 | 121 | 360 | 481 | 160 | 45 | 6.380.000 |
| SJ - 30 H | 3 | 126 | 480 | 606 | 190 | 65 | 9.475.000 |
| SJ - 50 H | 5 | 150 | 410 | 560 | 200 | 85 | 13.475.000 |
| SJ - 100 H | 10 | 160 | 400 | 560 | 250 | 135 | 24.750.000 |
